PyQt – automatically resize widgets/images
I’m working on a software that takes a picture from a CAM and puts it into a widget window. Since my picture is 640×480, I want it to resize the picture to fit the window so that the user can resize the window to zoom in or out of the image.
I did the following algorithm:
- Gets the widget size
- Scales are calculated based on the height of the picture and widget
- Resize the picture
- Display the picture
So far, it works well, but there are problems. When I open the program it starts to grow indefinitely, I know that this happens because the widget is expanding and the picture is getting bigger because the window is increasing in the first place, which is a positive feedback.
However, I’ve tried changing the size policy to preferred, fixed, etc., but none of them worked.
My window structure looks like this: Widget->VLayout->Label (Pixmap image).
Solution
One possible solution is to create a custom widget and override the paintEvent method, as shown in the following code.
class Label(QWidget):
def __init__(self, parent=None):
QWidget.__init__(self, parent=parent)
self.p = QPixmap()
def setPixmap(self, p):
self.p = p
self.update()
def paintEvent(self, event):
if not self.p.isNull():
painter = QPainter(self)
painter.setRenderHint(QPainter.SmoothPixmapTransform)
painter.drawPixmap(self.rect(), self.p)
class Widget(QWidget):
def __init__(self, parent=None):
QWidget.__init__(self, parent=parent)
lay = QVBoxLayout(self)
lb = Label(self)
lb.setPixmap(QPixmap("car.jpg"))
lay.addWidget(lb)
app = QApplication(sys.argv)
w = Widget()
w.show()
sys.exit(app.exec_())
